TRIJICON RMR OPTIC CUT MACHINING SERVICE FOR CUSTOMER SUPPLIED GLOCK SLIDES
INCLUDES (2) PAIRS 4-40 x 3/8" TORX: T10 MOUNTING SCREWS
SLIDE DISASSEMBLY INCLUDED FOR ALL ORDERS/SLIDE RE-ASSEMBLY AND IRON SIGHT INSTALL INCLUDED FOR ALL ORDERS (SOME LIMITATIONS APPLY)
NEW STRIKER CHANNEL LINER INSTALLED ON ALL SLIDE MACHINING ORDERS INCLUDING RE-FINISHING
ALLOWS FOR MOUNTING ANY MODEL TRIJICON RMR (TYPE 1 OR TYPE 2) DIRECTLY TO YOUR GLOCK SLIDE WITH A REDUCED MOUNTED HEIGHT VERSUS DOVETAIL PLATES OR MOS SLIDES
OPTIC CUT DEPTH OF .150" INCLUDES FRONT INDEXING POSTS AND INTEGRAL INDEXING POSTS AROUND MOUNTING SCREW HOLES
OUR TRIJICON RMR CUT ALSO WORKS WITH THE HOLOSUN 507C/407C/508T OPTICS BUT REQUIRES SHORTER MOUNTING SCREWS (THOSE CAN BE ORDERED HERE) NOTE: RECOMMENDED ABSOLUTE CO-WITNESS IRON SIGHT HEIGHT IS DIFFERENT FOR THE HOLOSUN 507C/407C/508T DUE TO LARGER WINDOW SIZE. THOSE RECOMMEND HEIGHTS CAN BE FOUND ON THE 507C/407C/508T OPTIC CUT PAGE
NOT COMPATIBLE WITH HOLOSUN 509T ADAPTER PLATE
IRON SIGHT CO-WITNESS HEIGHTS:
AMERIGLO SIGHT SET (.260" TALL FRONT/.355" TALL REAR): LOWER 1/4 CO-WITNESS
AMERIGLO 1XL .315" TALL FRONT/.394" TALL REAR: LOWER 1/3 CO-WITNESS
AMERIGLO 3XL .365" TALL FRONT/.451" TALL REAR: ABSOLUTE CO-WITNESS
TRIJICON SUPPRESSOR SIGHTS .365" TALL FRONT/.451" TALL REAR: ABSOLUTE CO-WITNESS
Do I need to send my RMR in with the slide? No, we do not need your optic for fitting. The Integral Indexing Posts and our CNC machining process make it unnecessary.
Will you install my sights/suppressor sights if I send them in with my slide? Yes, iron sight installation is included for all slides, with the exception of slides machined with a new dovetail in front of optic not being re-finished. Just choose the appropriate option in the Iron Sight Installation drop down menu.
SHIPPING INSTRUCTIONS FOR SENDING IN YOUR SLIDE/PARTS
INCLUDES PATENTED OPTIC CUT TECHNOLOGY PIONEERED BY ZEV TECHNOLGIES (PATENT RE47335)
The RMR fits nice and snug into the cut. I'm not concerned about much zero shift if the optic needs to be removed and reinstalled, it's that snug.
Turnaround was about nine days. Great communication, they emailed with each step in the process. Shipped it back quickly at a good price, and the charge for machining this good is a bargain. Highly recommend. BPMinME on 21st Oct 2022
Workmanship and quality far exceed the highest of expectations. This work is flat out extraordinary. Jake O. on 17th Jul 2022
Superb customer service, wanted to make a change to the finish to nitride after the order had been placed and they made the change to the order within 24 hours. Shipped 5/27, received back to me 6/16. Just under three weeks between receipt, machining, refinishing, and return. The cutout is extremely well done, finish is perfect, could not ask for a better first experience. Unknown on 16th Jun 2022
